TXR 425 - Technical Specifications and Characteristics

Standard Frequency Series Generators
Operation
17
M-2008-7-14
SECTION 6
TECHNICAL SPECIFICATIONS
6.1 FACTORS
FACTORS
Generator Model
TXR 325 D
TXR 325 M
TXR 425
TXR 525 SFQ
Maximum Power kW
40 kW 50 kW
Maximum mA
400 Ma 500 mA
Maximum kVp
125 kVp 125 kVp
Power Output (@ 0.1s)
(Nominal Electric Power)
400 mA @ 100 kVp 500 mA @ 100 kVp
6.2 RANGE OF RADIOGRAPHIC PARAMETERS
PARAMETER RANGE
KVp
From 50 kVp to 125 kVp in 1 kVp steps.
Ma
From 50 mA to 500 mA through the following mA Stations:
50, 100, 150, 200, 300, 400, 500 (Depending on the generator model).
MAs Product of mA x Time values from 0.4 mAs to 600 mAs
EXPOSURE TIME
TIME CHART IN SECONDS AND FRACTIONS 60 HERTZ
.008s
1/120
.016s
1/60
.025s
1/40
.033s
1/30
.041s
1/24
.050s
1/20
.066s
1/15
.083s
1/12
.100s
1/10
.150s
3/20
.200s
1/5
.250s
1/4
.300s
3/10
.400s
4/10
.500s
1/2
.750s
¾
1.00s
1
1.25s
1 1/4
1.50s
1 1/2
2.00s
2
2.50s
2 1/2
3.00s
3
6.00s
6
TIME CHART IN SECONDS (S) 50 HERTZ
.01s .02s .03s .04s .05s .06s .08s .10s
.12s .18s .24s .30s .36s .48s .60s .90s
1.2s 1.5s 1.8s 2.4s 3.0s 3.6s 7.2s
6.3 DUTY CYCLE
The generator duty cycle is as follows: 1% Condition is 500 mA @ 125 kVp for 5 seconds, every 5 minutes.
Limits should be set during installation depending on the capacity of the X-ray tube.
