Port Q'ty (4)
LAN
Controller Intel 82574 / Intel 82576
Connector (2) Mini SAS connectors (support 8 ports)
Controller LSI SAS1068E
Speed 3.0 Gb/s
SAS
(optional)
RAID S/W RAID 0/1/1E
Connector (6)
Controller ICH10R
Speed 3.0 Gb/s
Storage
SATA
RAID S/W RAID 0/1/10/5 (Intel Matrix RAID)
Connector type D-Sub 15pin
Resolution 1600x1200
Graphic
Chipset Aspeed AST2050
USB
(7) USB2.0 ports (4 at rear, 2 via cable, 1 type A
onboard)
COM (1) port (rear)
SAS (2) Mini SAS (4 in 1) connectors (optional)
VGA (1) D-Sub 15pin VGA port
RJ-45 (4) GbE ports
Power SSI 24-pin + 8-pin + 8-pin power connectors / EPS 12V
Front Panel (1) 2x12 pin SSI Front Panel header
Input
/Output
SATA (6) SATAII connectors
Chipset Winbond W83793G
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (5) 4-pin headers
System
Monitoring
Temperature Monitors temperature for CPU & system environment
