LED
Fan fail LED indicator / Over temperature warning
indicator
Others Chassis intrusion detection / Watch Dog timer support
Onboard Chipset Onboard Aspeed AST2050
AST2050 IPMI
Feature
IPMI 2.0 compliant baseboard management controller
(BMC) / Supports storage over IP and remote platform-
flash/ BIOS update / USB 2.0 virtual Hub
Server
Management
AST2050 iKVM
Feature
24bit High quality video compression / Dual 10/100 Mb/s
MAC interfaces
Brand / ROM size 4MB / AMI / SPI Flash ROM
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE
Boot / ACPI 2.0 power management /Power on mode
after power recovery / User-configurable H/W monitoring
/ Auto-configurable of hard disk types / Multiple boot
options
Form Factor SSI EEB
Form Factor
Board Dimension 12"x13" (305x330mm)
Operation
System
OS supported list
Please refer to the OS supported list at
http://www.tyan.com/tech/os_support1.aspx
FCC (Doc) Class B
CE (Doc) Yes
C-Tick Yes
Regulation
VCCI Yes
Operating Temp 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp
- 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Complaint Yes
Motherboard (1) TYAN motherboard
Manual (1) User's manual / (1) Quick Ref. Guide
Installation CD (1) TYAN Installation CD
I/O Shield (1) I/O Shield
SATA (6) SATA signal cables
Accessory
list
Cable
SAS (2) Mini-SAS 1-to-4 cables (optional)
