7
RJ-45
(2) 10GbE ports, (1) Dedicated for
IPMI
Audio
LINE_IN, LINE_OUT, MIC_IN
connectors
Front Panel (1) 2x12-pin SSI front panel header
SATA
(2) SATA-III connectors + (2) Mini-
SAS (4-in-1) connectors
Power
SSI 24-pin + 8-pin + 8-pin power
connectors
Others (1) UID button
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset Aspeed AST2500
Fan Total (5) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Over temperature warning
indicator, Fan & PSU fail LED
indicator
Others Watchdog timer support
Server Management
AST2500 iKVM
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
Supports storage over IP and
remote platform-flash, USB 2.0
virtual hub
AST2500 IPMI
Feature
24-bit high quality video
compression, 10/100/1000 Mb/s
MAC interface
BIOS
Brand / ROM size AMI, 32MB
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
sleeping states S4,S5, ACPI 6.1
Physical Dimension
Form Factor Proprietary
Board Dimension 14.2" x 13.2" (361.5 x 336.2mm)
Regulation
FCC (DoC) Class B
CE (DoC) Class A
