Tyco 530010040 User Manual

TFP1326
Page 12 of 22
Note:
Port Connections P1 through P7 are described in Figure 2.
External Trim Connections
C1
C2
C3
C4
C5
Diaphragm Supply Connection
Water Motor Alarm Connection
Waterow Pressure Alarm
Switch Connection
Main Drain Connection
Drip Funnel Drain Connection
Item Description
A
B
C
D
E
F
G
H
DV-5A Valve
System Main Control Valve
Waterow Pressure Switch
Main Drain Valve
System Drain Valve
Automatic Drain Valve
Alarm Test Valve
Alarm Control Valve (Optional)
Item Description
J
K
L
M
N
P
Q
R
Water Supply Gauge
Diaphragm Gauge
(Not Used)
Manual Control Station
Solenoid Valve
Diaphragm Supply Valve
Diaphragm Supply Strainer
Inverted Flare Shut-Off Valve
LOCATION
FOR OPTIONAL
ELECTRICALLY
SUPERVISED
N.O. ALARM
CONTROL
VALVE
C4
C2
C5
C1
C3
G
P
Q
J
B
M
F
N
E
A
D
K
R
C
H
P1
P2
P3
P6
P7
P4
P5
FIGURE 9
DV-5a VALVE — REMOTE-RESETTING, PRESSURE-REDUCING TRIM
(Refer to Figure 6 for specific Bills of Materials)
