Tyco 530010040 User Manual

TFP1326
Page 9 of 22
ITEM QTY. DESCRIPTION CH 3 IN. (DN80) 4 IN. (DN100) 6 IN. (DN150) 8 IN. (DN200)
22 1 STREET ELBOW
✓
1/4" x 90° 1/4" x 90° 1/4" x 90° 1/4" x 90°
23 1 ELBOW
✓
1/2" x 45° 1/2" x 45° 1/2" x 45° 1/2" x 45°
24 4 ELBOW
✓
1/2" x 90° 1/2" x 90° 1/2" x 90° 1/2" x 90°
25 4 TEE
✓
1/2" 1/2" 1/2" 1/2"
26 2 REDUCING TEE
✓
1/2" x 1/2" x 1/4" 1/2" x 1/2" x 1/4" 1/2" x 1/2" x 1/4" 1/2" x 1/2" x 1/4"
27 1 REDUCING TEE
✓
1/2" x 1/2" x 3/4" 1/2" x 1/2" x 3/4" 1/2" x 1/2" x 3/4" 1/2" x 1/2" x 3/4"
28 1 REDUCING CROSS
✓
1/2" 1/2" 1/2" 1/2"
29 1 REDUCING TEE
✓
1-1/4” x 1-1/4” x 3/4” 2” x 2” x 3/4” 2” x 2” x 3/4” 2” x 2” x 3/4”
30 1 PIPE NIPPLE
✓
1/4" x 1-1/2" 1/4" x 1-1/2" 1/4" x 1-1/2" 1/4" x 1-1/2"
31 5 PIPE NIPPLE
✓
1/2" x CLOSE 1/2" x CLOSE 1/2" x CLOSE 1/2" x CLOSE
32 7 PIPE NIPPLE
✓
1/2" x 1-1/2" 1/2" x 1-1/2" 1/2" x 1-1/2" 1/2" x 1-1/2"
33 2 PIPE NIPPLE
✓
1/2" x 2" 1/2" x 2" 1/2" x 2" 1/2" x 2"
34 2 PIPE NIPPLE
✓
1/2" x 2-1/2" 1/2" x 2-1/2" 1/2" x 2-1/2" 1/2" x 2-1/2"
35 1 PIPE NIPPLE
✓
1/2" x 3" 1/2" x 3" 1/2" x 3" 1/2" x 3"
36 1 PIPE NIPPLE
✓
1/2" x 4-1/2" 1/2" x 4-1/2" 1/2" x 4-1/2" 1/2" x 4-1/2"
37 1 PIPE NIPPLE
✓
3/4" x 1-1/2" 3/4" x 1-1/2" 3/4" x 1-1/2" 3/4" x 1-1/2"
38 — ITEM NOT USED — — — —
39 1 PIPE NIPPLE
✓
1/2” x 4-1/2” 1/2” x 5-1/2” 1/2” x 5-1/2” 1/2” x 6-3/4”
40 1 PIPE NIPPLE
✓
1/2” x 3-1/2” 1/2” x 4” 1/2” x 6-3/4” 1/2” x 6-3/4”
41 1 PIPE NIPPLE
✓
1/2” x 6-3/4” 1/2” x 9-1/2” 1/2” x 9-1/2” 1/2” x 9-1/2”
42 1 PIPE NIPPLE
✓
1-1/4” x 3-1/4” 2” x 3” 2” x 3” 2” x 3”
43 1 PIPE NIPPLE
✓
1-1/4” x 5-1/2” 2” x 5” 2” x 6” 2” x 8”
44 1 TUBING ASSY, MC-2 ACTUATION RELIEF 545100052 545100052 545100052 545100052
45 1 TUBING ASSY, SOLENOID ACTUATION RELIEF 545100037 545100038 545100039 545100040
46 1 TUBING ASSY, ALARM TEST INTERCONNECT 545100043 545100044 545100045 545100046
47 1 TUBING ASSY, SYSTEM DRAIN 535000430 535000440 535000460 535000480
48 2
WATER PRESSURE GAUGE, 300 PSI / 2000 kPa
(AMER/APAC)
923431005 923431005 923431005 923431005
48 2
WATER PRESSURE GAUGE, 20 bar / 2000 kPa
(EMEA)
025500013 025500013 025500013 025500013
49 1 LABEL 545003003 545003003 545003003 545003003
50 1 LABEL WIRE 545003003 545003003 545003003 545003003
A1 1 DV-5A VALVE, G x G
REFER TO TABLE F FOR DV-5A PART NUMBERS
A2 1
WATERFLOW PRESSURE ALARM SWITCH,
PS10-2 (AMER/APAC)
25710 25710 25710 25710
A2 1
WATERFLOW PRESSURE ALARM SWITCH,
PS10-1 (EMEA)
0260 0260 0260 0260
A3 1 BFV-300 BUTTERFLY VALVE, G x G 59300G030WS 59300G040WS 59300G060WS 59300G080WS
A4 1 FIGURE 577 RIGID GROOVED COUPLING 57730ACP 57740ACP 57760ACP 57780ACP
A5 1 SOLENOID VALVE 2460566 2460566 2460566 2460566
A6 1 INVERTED FLARE SHUT-OFF VALVE
a
545100099 545100100 545100100 545100100
A7 1 TUBING ASSY, DIAPHRAGM CHAMBER SUPPLY 545100053 545100055 545100056 545100057
A8 1 FLARE FITTING 90° 1/2” NPT x 1/2” TUBE 545100062 545100062 545100062 545100062
NOTE:
a. Not VdS Approved
CH - Common Hardware - Refer to Materials of Construction section for specications.
FIGURE 7 (2 OF 2)
DV-5A VALVES — REMOTE-RESETTING, PRESSURE-REDUCING TRIM
EXPLODED VIEW
