11
1.5.1 ENCLOSURE ASSEMBLY
Contact your local representative for other available configurations that are not listed above.
Enclosure Assemblies
Description Catalog number Part number Weight/lbs
DigiTrace 920 controller–2 Pt in a 14" x 12" x 8" FRP enclosure
with window and quick-release latches, control module, and oper-
ator console. 1P 30 A 277 V SSR/pt. Controls two circuits, each
with a 1-pole solid-state relay. (Approved for Class 1, Div. 2 areas)
920*E4FWL*SIS302*SS3102*HTC*CON 10160-010 27
DigiTrace 920 controller–2 Pt in a 14" x 12" x 8" FRP enclosure
with window and quick-release latches, control module, and oper-
ator console. Includes an isolated 2-wire RS-485 communication
option. 1P 30 A 277 V SSR/pt. Controls two circuits, each with a
1-pole solid-state relay. (Approved for Class 1, Div. 2 areas)
920*E4FWL*SIS302*SS3102*HTC485*CON 10160-011 27
DigiTrace 920 controller–2 Pt in a 14" x 12" x 8" FRP enclosure
with window and quick-release latches, control module, and oper-
ator console. 2P 30 A 277 V SSR/pt. Controls two circuits, each
with a 2-pole solid-state relay. (Approved for Class 1, Div. 2 areas)
920*E4FWL*SIS302*SS3202*HTC*CON 10160-012 32
DigiTrace 920 controller–2 Pt in a 14" x 12" x 8" FRP enclosure
with window and quick-release latches, control module, and oper-
ator console. Includes an isolated 2-wire RS-485 communication
option. 2P 30 A 277 V SSR/pt. Controls two circuits, each with a
2-pole solid-state relay. (Approved for Class 1, Div. 2, areas)
920*E4FWL*SIS302*SS3202*HTC485*CON 10160-013 32
DigiTrace–DigiTrace Supervisory Software DigiTrace Supervisor 10391-002 1
Note: The NEC (and CEC) rules specify that all ungrounded—i.e., hot—legs of a circuit, must be switched in the event of a ground fault. This means for
207 V single-phase applications, you must specify a 2-pole (2P) version if you are not using external GFI breakers.
Control Modules
DigiTrace 920 controller–Control module only
(No communications options installed)
920HTC 10260-001 1
DigiTrace 920 controller–Control module with an isolated
2-wire RS-485 communication option installed
920HTC*485 10260-004 1
DigiTrace 920 controller–Control module with modem
communications option installed
920HTC*MDM 10260-002 1
Operator Console
DigiTrace 920 controller–Operator console 920CON 10260-005 1
