Internet Alarm Communicator Installation Manual
Table 7: Supervision Intervals for UL/ULC
[005] System Toggle Options
[1] Ethernet Receiver 1 Supervised Default (OFF)
ON: Ethernet receiver 1 will be supervised and heartbeats will be sent to Ethernet receiver
1 based on the supervision interval programmed in section [004].
OFF: Ethernet receiver 1 will not be supervised. When disabled, heartbeat 1 is sent to the
Ethernet receiver once every hour, regardless of supervision type (heartbeat 1 or 2). The
heartbeat is resent every 5 seconds until ACK. If no event or heartbeat ACK is received
after (receiver supervision interval + 75 seconds), supervisory trouble is indicated.
NOTE: Ethernet receiver 2 can not be supervised.
[2] Reserved
[3] Supervision Type Default (OFF)
ON: Heartbeat 1 (commercial supervision). This supervision type is suitable for applica-
tions where swap detection is required on the supervisory packet.
OFF: Heartbeat 2 (residential supervision). This supervision type is suitable for applica-
tions where supervision of the communication path to the receiver is required. (no swap
detection).
NOTE: Commercial supervision is more data intensive than residential supervision and should
only be used when required to meet the approval for the installation.
OFF: Events will be communicated to the receivers individually.Toggle should be OFF
when guaranteed message delivery to both receivers is required.
[4] Reserved
[5] Reserved
[6] Remote Firmware Upgrade Default (ON)
ON: The communicator module firmware can be remotely upgraded using the Ethernet net-
work.
OFF: The communicator module firmware can not be remotely upgraded. Local firmware
upgrade is still possible.
[7] Alternate Test Transmissions Default (OFF).
ON: When the periodic test transmission interval occurs, the test transmission will alternate
between being sent to the primary and secondary receivers with each test transmission
interval.
OFF: When the periodic test transmission interval occurs, the test transmission will be sent
to the programmed receivers, based on the settings of the periodic test transmission report-
ing codes.
[8] Reserved
Jurisdiction Receiver Window (Timeout)
Recommended Supervision
Interval
UL Commercial Burglary 200 seconds (0087/135) seconds
UL Residential Fire 30 days Panel Test Transmission
UL Residential Burglary 30 days Panel Test Transmission
ULC Commercial Burglary Active 180 seconds (005A/90) seconds
ULC Commercial Burglary Passive 24 hours Panel Test Transmission
ULC Commercial Burglary Fire Active 180 seconds (0073/115) seconds
ULC Commercial Burglary Fire Passive 24 hours Panel Test Transmission
