Tyco Star A-1 User Manual

STAR SPRINKLER INC.
Page 6
2-2.1.31
8-3/8"
(212.7 mm)
24-1/4"
(616.0 mm)
6-7/8"
(174.6 mm)
15"
(381.0 mm)
8-1/2"
(215.9 mm)
16-1/4"
(412.8 mm)
23"
(584.2 mm)
FIGURE 7
OPTIONAL MODEL S430 DRY PIPE VALVE ACCELERATOR
(Refer to Product Data Sheet 2-5.4.10 for complete information)
FIGURE 6
4 INCH (DN100) MODEL A-1 DRY PIPE VALVE AND TRIM INSTALLATION DIMENSIONS
TO SYSTEM PIPING
1/2" NPT CONNECTION
ACCELERATOR
CONTROL VALVE
REAR VIEWRIGHT SIDE VIEW
RESET
VENT
PLUG
KNOB
(381.0 mm)
15"
ACCELERATOR
MODEL S430
(749.3 mm)
29-1/2"
(336.6 mm)
13-1/4"
(NORMALLY OPEN)
1/2" NPT ACCELERATOR TRIM
CONNECTION TO DRY PIPE VALVE
INTERMEDIATE CHAMBER
OBSOLETE
