LOADER MOUNTING
CAUTION:
CAUTION:CAUTION:
CAUTION:
When the hook is right over the pin.
Never allow weight of tractor to be put on
parking leg when mounting loader.
STEP
STEPSTEP
STEP 1.
1.1.
1. Carefully drive the tractor into the loader
to a position where the hydraulic hoses(Quick
coupler) can be connected to the control valve
STEP
STEPSTEP
STEP 4.
4.4.
4. Move the tractor forward to put the
post into the mounting frame. Stop the
tractor
Lower the mounting frame with moving the
boom and bucket until it hooked securely
each other.
- 14 -
Insert the latch pins.
STEP
STEPSTEP
STEP 3.
3.3.
3. Start the engine and move the boom
and bucket to adjust the height of post.
Be sure to check the pin welded of post is
slightly higher than the hook on mounting frame.
STEP
STEPSTEP
STEP 2.
2.2.
2. Stop the engine and move the control
lever back and forth, Left and right several times
to reduce the pressure in the hydraulic hoses.
Connect the hydraulic couplers match the color
code rings.
the bucket and boom.
Rubber hammer can be used to put the pin in
if needed.
STEP
STEPSTEP
STEP 6.
6.6.
6. Remove pin and keeper holding the
parking legs and return to storage position.
Make secure by using pin and keeper.
- 14 -
