BOOM ASSEMBLY
(UPDATED 03, 31, 2009)
(SELF-LEVEL TYPE)
REF.NO
REF.NOREF.NO
REF.NO PART.NO
PART.NOPART.NO
PART.NO DESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION QTY
QTYQTY
QTY I.C
I.CI.C
I.C SERIAL OR DATE
SERIAL OR DATESERIAL OR DATE
SERIAL OR DATE
1 LTF54-14100-01 BOOM W.A 1
~80127027
1 LTF54-14100-02 BOOM W.A 1
80423001~
2 LTM45-14300 TOP POST W.A-LH 1
2 LTM45-14300-01 TOP POST W.A-LH 1
70223010~
3 LTM45-14400 TOP POST W.A-RH 1
3 LTM45-14400-01 TOP POST W.A-RH 1
70223010~
4 LTS21-51210-01 LINK-LEVEL 2
5 LTM45-21600 SAFETY-BAR 2
6 50140-M600K STARP-LOCK, 600L 2
7 LTS19-51110-01 LINK LH 1
7 LTS19-51110-02 LINK LH 1
~80611029
7 FTF38-51300 LINK LH 1
08.29.2008~
8 LTS19-51120-01 LINK RH 1
8 LTS19-51120-02 LINK RH 1
~80611029
8 FTF38-51400 LINK RH 1
08.29.2008~
9 LTS19-61111 STAND 2
9 LTS19-61111-01 STAND 2
70223010~
10 LTS19-61120 STAND W.A 2
10 LTS19-61120-01 STAND W.A 2
70223010~
11 LTS21-61130 BOLT W.A 2
12 LTS19-51400 LINK W.A 2
12 LTS19-51400-01 LINK W.A 2
70223010~
13 LTS19-51330 LINK W.A, BUCKET 1
14 LTS19-51310 LINK W.A, BUCKET 1
15 LTS19-51320 LINK W.A, BUCKET 1
16 LTS19-51340 LINK W.A, BUCKET 1
17 LTS19-31500B PIN W.A 2
17 14133-25113-N PIN W.A, Φ25-113L 2
12.01.2008~
18 14021-10000 RING PIN, Φ10 2
19 LTS19-71211 PIN, M24-148L 18
20 LTS19-71212 PIN, M24-123L 2
21 1021M-M2404 NUT-SELFLOCK, M24-1.5P 18
22 10321-M2400 WASHER-PLAIN, M24 4
23 LTL26-61201 PIN-HEAD, Φ16-110L, H67.5 2
24 14011-03000 R-PIN, Φ3 2
25 10191-M160F-90 HEX.BOLT, M16-2.0 90L 2
26 1021N-M1606 NUT-SELFLOCK, M16-2.0P 2
27 10321-M1600 WASHER-PLAIN, M16 6
28 10191-M120E-50 HEX.BOLT, M12-1.75P 50L 2
29 1021N-M1205 NUT-SELFLOCK, M24-1.75P 2
30 LTS26-81201 BAR GAUGE SHORT, Φ17.3 1
30 LTM45-21703 BAR GAUGE SHORT, Φ17.3 1
31 LTS21-81202 BAR GAUGE LONG, Φ12 1
31 LTM45-21702 BAR GAUGE LONG, Φ12 1
32 S1053-51035 HEX.BOLT , M10-35L 2
32 10121-M1004-30 HEX.BOLT , M10-1.5P 30L 2
33 S4013-50100 WASHER SPRING, M10 1
33 10211-M1004 HEX.NUT, M10-1.5P 1
34 802G0-T1900 GREASE NIPPLE, PT1/8 24
-27 -
