HYDRAULIC PIPING (UPDATED 09, 18, 2008)
(SELF-LEVEL TYPE)
REF.NO
REF.NOREF.NO
REF.NO PART.NO
PART.NOPART.NO
PART.NO DESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION QTY
QTYQTY
QTY I.C
I.CI.C
I.C
SERIAL OR DATE
SERIAL OR DATESERIAL OR DATE
SERIAL OR DATE
1 2254-1000 BOOM CYLINDER ASS'Y 2
1 225603 BOOM CYLINDER ASS'Y 2
70402068~
2 LTS21-82120 BUCKET CYLINDER ASS'Y-LH 1
2 226201 BUCKET CYLINDER ASS'Y-LH 1
70402068~
3 2254-4000 BUCKET CYLINDER ASS'Y-RH 1
3 226202 BUCKET CYLINDER ASS'Y-RH 1
70402068~
6
801T1-50000
VALVE, RELIFE 1
7
802N2-P46F9-42
NIPPLE, PF3/8, O-RING x3/4-16UNF 4
8
802L2-F94F9-40
NIPPLE, 3/4-16UNF, HOSE.3/4-16UNF, HOSE.90˚ 1
9
802T2-F94F9-40
NIPPLE, 3/4-16UNF, HOSE-T TYPE 4
11 802L2-P46F9-42 NIPPLE, PF3/8, O-RING x3/4-16UNF 90˚ 8
12 81301-BP014 O-RING, 1PB14 12
13 LTS21-11200 COVER, PIPE 1
14 0001-1006 QUICK COUPLER, MALE 4
14 80420-T3360 QUICK COUPLER, PT 3/8" FEMALE 4
15 LTF54-1184A PIPE ASS'Y 1
15 LTS21-81510 PIPE ASS'Y 1
6022001~
16 LTF54-1184C PIPE ASS'Y 1
16
LTS21-81520
PIPE ASS'Y
1
6022001~
X
16
LTS21-81520
PIPE ASS'Y
1
6022001~
17 LTF54-1184D PIPE ASS'Y 1
17 LTS21-81530 PIPE ASS'Y 1
6022001~
18 LTF54-1184E PIPE ASS'Y 1
18 LTS21-81540 PIPE ASS'Y 1
6022001~
19 LTF54-1184F PIPE ASS'Y 1
19 LTS21-81550 PIPE ASS'Y 1
6022001~
20 LTF54-1184H PIPE ASS'Y 1
20 LTS21-81560 PIPE ASS'Y 1
6022001~
21 LTF54-1184G PIPE ASS'Y 1
21 LTS21-81570 PIPE ASS'Y 1
6022001~
22 LTF54-1184J PIPE ASS'Y 1
22 LTS21-81580 PIPE ASS'Y 1
6022001~
23 LTF54-1184B PIPE ASS'Y 1
23 LTS21-81590 PIPE ASS'Y 1
6022001~
24 LTF54-11946 HOSE ASS'Y 1
24 LTS21-81610 HOSE ASS'Y, 904(3/4-16UNF)-4(3/4-16UNF) 900L(3/8) 1
6022001~
24 80620-05036
HOSE ASS'Y, 904(3/4-16UNF)-4(3/4-16UNF) 1000L(3/8)
1
25 LTF54-11941 HOSE ASS'Y 2
25 LTF54-11947 HOSE ASS'Y 2
25 LTS21-81630 HOSE ASS'Y, 4(3/4-16UNF)-4(3/4-16UNF) 700L(3/8) 2
25 80620-12006 HOSE ASS'Y, 454(3/4-16UNF)-4(3/4-16UNF) 700L(3/8) 2
26 LTF54-11944 HOSE ASS'Y 1
26 LTS21-81620 HOSE ASS'Y, 904(3/4-16UNF)-4(3/4-16UNF) 400L(3/8) 1
6022001~
27 LTF54-11945 HOSE ASS'Y 1
27 LTS21-81640 HOSE ASS'Y, 4(3/4-16UNF)-4(3/4-16UNF) 900L(3/8) 1
6022001~
27 80620-03007 HOSE ASS'Y, 4(3/4-16UNF)-2(3/4-16UNF) 1000L(3/8) 1
28 LTF54-11943 HOSE ASS'Y 1
28 LTS21-81650 HOSE ASS'Y, 4(3/4-16UNF)-4(3/4-16UNF) 400L(3/8) 1
6022001~
28 80620-05062 HOSE ASS'Y, 4(3/4-16UNF)-2(3/4-16UNF) 400L(3/8) 1
- 29 -
