TYM MM60 User Manual

MOUNT KIT SERVICE PARTS BREAKDOWN
NO QTY PART DESCRIPTION
1 1 JHM 1000-056-100
2 1 JHM 1000-057-100
3 1 JHM 1000-030-100
4 1 JHM 1000-031-100
5 1 JHM 1000-032-100
6 1 JHM 1000-088-100
7 1 JHM 1000-086-100
8 2 JHM 1000-046-100
9 1 JHM 1000-060-100
10 1 JHM 1000-061-100
11 1 JHM 1000-058-100
12 1 JHM 1000-087-100
13 1 JHM 1000-090-100
14 2 JHM 1000-055-100
15 1 JHM 1000-048-100
16 1 JHM 1000-047-100
17 1 JHM 1000-059-100
18 1 JHM 1000-038-100
19 1 JHM 1000-040-100
20 2 JHM 1000-050-101
21 2 JHM 1000-050-102
22 1 JHM 1000-044-100
23 1 JHM 1000-053-100
24 1 JHM 1000-051-100
25 1 JHM 1000-001-100
26 1 JHM 1000-089-100
27 2 JHM 1000-064-100
28 2 JHM 1000-062-100
29 2 JHM 1000-063-100
30 2 JHM 1000-065-100
31 1 JHM 1000-091-100
32 2 JHM 1000-094-100 LINK SPRING
33 1 JHM 1000-092-100 SPRING
34 2 JHM 1000-084-100 RING
35 2 JHM 1000-039-103 FLAT WASHER
36 4 H100-100-007
37 4 H100-100-005
38 20 H100-100-006
39 1 H100-100-007
40 4 H100-100-003
Hex Head Cap Screw_M12 X L45
Hex Head Cap Screw_M12 X L35
Hex Head Cap Screw_M10 X L55
UNIVERSAL JOINT ASSY
LOCKING PIN
LINK PIN-3
LINK PIN-1
LINK PIN-2
LINK ASSY PIN
ROTATION BOLT
Hex Head Cap Screw_M16 X L45
Hex Head Cap Screw_M14 X L35
LINK BODY
LINK BOLT
SHAFT
LINK BRACKET-RH SUB ASSY
LINK PLATE-2
LINK PLATE-LH
LINK BRACKET-LH SUB ASSY
ROTARION WELDING ASSY-LH
LINK PIN GUIDE ASSY
ROTATION LINK ASSY-RH
LATCH PIN ASSY
LINK PLATE-RH
ANCHOR SUB ASSY-LH
ANCHOR SUB ASSY-RH
LINK PLATE-LH
FIXING PLATE-LH
FIXING PLATE-RH
MOVING WELDING ASSY-1
MOVING WELDING ASSY-2
MOVING WELDING ASSY-3
DISTANCE ADJUSTMENT PLATE WELDING ASSY
ANCHOR BRACKET WELDING ASSY
STOP PLATE SUB ASSY
LINK PLATE-1
