GENERAL INFORMATION
A
8
• REAR AXLE & WHEELS
This is mounted on ball bearings and is
enclosed in removable housing which
are bolted to the transmission case.
The rim & disc fitted with rear tires are
bolted to the outer flange of rear axle.
• HYDRAULIC SYSTEM & LINKAGES
TYM tractors are fitted with live
independent, very touch of hydraulic
system.
Three point linkages can be used for
category 1 type of implements.
• STEERING
It consists of Hydrostatic Power
steering system, which has a hydraulic
cylinder and single type hydraulic
pump.
• ENGINE
The T194 tractor is fitted with vertical,
Water-cooled 3-cycle and spherical
chamber type YANMAR ENGINE
(3TNV74F-SDKTF2).
• TRANSMISSION
The T194 is fitted HST with 2 range and
can be selected speed range by HIGH-
LOW selector lever.
The T194 tractor has Two pedals for
forward/reverse control.
T194 tractor with Independent Power
Take Off is fitted with electro hydraulic
Clutch Assy.
The Mid PTO can be operated both or
separately by a lever.
TYM T194 tractor are provided with
independent disc brakes operated by
two road travel.
A foot brake lever is fitted for parking.
▶ DESCRIPTION
• GENERAL CONSTRUCTION
The transmission case, engine and
front axle support are bolted together
to form a rigid unit.
• FRONT AXLE & WHEEL
The 4WD front axle is a center-pivot,
reverse eliot type.
The front wheel drive mechanism is
incorporated as a part of the axle.
The front wheel drive power is taken off
the rear transmission and transmitted
to the differential in the front axle where
the power is divided into right and left
and to the respective final cases.
In the final cases, the transmitted
revolution is reduced by the level gears
to drive the front wheel.
The 4WD mechanism with level gears
provides wider steering and greater
durability.
