C
TRACTOR INSTRUMENTS
C
▶ MONITOR PANEL
5
TURN SIGNAL
LAMPS
LOW BEAM LAMP
ENGINE OIL
PRESSURE LAMP
ENGINE WARNING
LAMP
PARKING BRAKE
LAMP
FUEL GAUGE
FUEL WARNING
LAMP
PTO LAMP
CRUISE CONTROL
LAMP
CHARGE WARNING
LAMP
GLOW LAMP
COOLANT
TEMPERATURE
WARNING LAMP
HOURMETER
TACHOMETER
2. MONITOR PANEL & GAUGES
