TRACTOR INSTRUMENTS
C
20
▶ FIGURE OF THREE POINT LINKAGE
4. THREE POINT LINKAGE
TOP LINK
LOWER LINK
PTO SHAFT
CHECK LINK
LIFT ROD
LOWER LINK
※ FIGURES OF BRAKE AND TURN SIGNAL LAMPS
MAY VARY DEPENDING ON SALES AREA
