TYM T194 Operator's Manual

OPERATION
D
4
▶ STOPPING AND PARKING
1. Operate the throttle lever to set the
engine at a low speed.
2. Release the forward driving (HST
type) and accelerator (mechanical)
pedals slowly. Depress the brake
pedals for abrupt braking.
3. When the vehicle is completely
stopped, set the shift lever in the
neutral position.
4. Apply the parking brake.
5. If an implement is attached to the
vehicle, lower it.
6. Remove the key from the switch
after parking vehicle.
▶ STARTING OFF, SHIFTING AND
DRIVING
1. Lift an implement.
2. Place the main shift lever, range
shift lever and shuttle shift lever
into the desired positions.
3. Depress the brake pedal to release
the parking brake.
▶ RUNNING-IN PERIOD
Make sure to keep the following
instructions for the initial 50-hour use.
1. Avoid abrupt starting and abrupt
stopping.
2. Do not use excessive speed or load.
3. Drive the T194 tractor only when
the engine is sufficiently warm.
4. Do not idle the engine at the
maximum speed.
5. Check each part and change oil and
fluid after 50-hour use.
6. Refer to the section Maintenance
for adding and changing engine oil.
2. OPERATING TRACTOR
 The driving speed in the reverse
direction is almost the same to the
speed in the forward direction.
Make sure to check the surroundings
carefully when driving backward.
 Especially, never drive backwards with
the range shift lever in the position H.
The driving speed becomes faster and it
can cause an accident.
WARNING
 After parking, make sure to apply the
parking brake.
 Avoid parking on a slope if possible. If it
is absolutely necessary to park on a
slope, chock the rear wheels.
WARNING
