TYM T194 - Checking and CHANGING OIL

6 - 5
MAINTENANCE AND SERVICE
43
6
(2) Changing

Unscrew the drain plug on the
lower section of the engine to
drain contaminated engine oil.
Since hot oil ows out of the en-
gine first, be careful not to get
burnt.

After draining oil, tighten the en-
gine oil drain plug.

Add the specied amount of the
specied engine oil through the
ller hole.
4. CHECKING AND CHANGING OIL
CHECKING AND CHANGING
ENGINE OIL
(1) Inspection
① Pull out the dipstick, wipe its tip
and insert it again. Then, pull it
out and check that the oil level
is between the upper and lower
limits.
② If insufcient, add oil.
►
T254O508A
Engine oil
gauge
Upper limit
Lower limit
Engine oil
gauge
Engine oil
cartridge
T19O504A
T19O505C
Engine oil
filler
Engine Oil Drain
