17. METRIC FASTENER(ISO) TORQUE CHART
Use these torques. Unless special torques are specied. Values are for UNF thread fastener, plated or un-plated as
received from supplier. Fasteners can be dry or lubricated with normal engine oil. Values do not apply if graphite.
Moly-disulphide or other extreme pressure lubricant is used.
NOTE
ISO Class No. 8.8 10.9 12.9
Bolt hed identication (see note 1)
Bolt Size
LB FT NM LB FT NM LB FT NM
MIN
MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
M4 2 3 3 4 3 4 4 5
Because of the low ductility
of these fasteners, the
torque range is to be
determined individually for
each application.
As a general rule, the
torque ranges specied for
grade 10.9 fasteners can
be used satisfactorily on
12.9 fasteners
* M14 is not a preferred
Size.
M5 5 6 6.5 8 7 8 7.5 11
M6 8 9 10.5 12 11 13 15 17.5
M8 19 23 26 31 27 32 27 43
M10 38 45 52 61 54 64 73 87
M12
66 79 90 75 93 112 125 150
*M14 106 127 144 172 149 179 200 245
M16 160 200 217 271 230 280 310 380
M20 320
380 434 515 450 540 610 730
M24
500 600 675 815 780 940 1,050 1,275
M30 920 1,100 1,250 1,500 1,470 1,770 2,000 2,400
M36 1,600 1,950 2,175 2,600 2,580 3,090 3,500 4,200
