TYM T194 - Informational Decals

3 - 14
OPERATION
12. INFORMATIONAL DECALS
5. Part NO : 9380-500-003-0
Located on Front of Deck Weldment
6. Part NO : 9397-500-008-0
Located on Deck Weldment
BELT ROUTING
7. Part NO : 9400-500-004-0
Located on Right of Deck Weldment
“A”
HEIGHT OF
CUT (INCHES)
2
2 1/2
3 (+)
B
A
GROUND
1/2 CLEARANCE
B
2
1
0
“B”
NO. OF
HOLES
