8. The difference between mea-
surement should be less than
3mm (0.12 in.).
9. If the difference between mea-
surement is more than 3mm
(0.12 in.), loosen the lock nut of
the left side.
10. Adjust the cutting height fine
turning bolts so that the differ-
ence between measurement L
and R is less than 3mm (0.12
in.). Then lock the nut.
Difference (L-R) Factory spec.
Between left tip and
right tip of blade
Less than
3mm ( 0.12 in.)
