▶GENERAL CONSTRUCTION
The transmission case, Engine and
Front Axle Support are bolted to-
gether to form a rigid unit.
▶FRONT AXLE & WHEELS
The 4WD front axle is a center-piv-
ot, reverse Eliot type. The front
wheel drive mechanism is incorpo-
rated as a part of the axle.
The front wheel drive power is taken
off the rear transmission and trans-
mitted to the differential in the front
axle where the power is divided into
right and left and to the respective
nal cases.
In the final cases, the transmitted
revolution is reduced by the level
gears to drive the front wheel. The
4WD mechanism with level gears
provides wider steering and greater
durability.
▶ENGINE
The Ride on lawnmower are fitted
with vertical, Water-cooled 3-cycle
and spherical chamber type YANMAR
ENGINE(3TNV74F-SDKTF2)
▶ TRANSMISSION WITH HST (HY
-
DROSTATIC TRANSMISSION)
The Ride on lawnmower is fitted
HST with 2 Range and can be se-
lected Speed range by HIGH-LOW
selector lever.
The Ride on lawnmower has Two
pedals for forward/reverse control .
Ride on lawnmower with Indepen-
dent Power Take Off is fitted with
electro-hydraulic Clutch Assy. The
Mid PTO can be operated both or
separately by a lever.
TYM Ride on lawnmower are pro-
vided with independent disc brakes
operated by two road travel. A foot
brake lever is tted for parking.
DESCRIPTION
▶REAR AXLE & WHEELS
This is mounted on ball bearings
and is enclosed in removable hous-
ing which are bolted to the transmis-
sion case. The rim & Disc tted with
Rear tires are bolted to the outer
ange of Rear Axle.
▶HYDRAULIC SYSTEM & LINK
-
AGES
TYM Ride on lawnmower are fitted
with Live (i.e. system is in operation)
independent, very touch of hydraulic
System.
▶STEERING
It consists of Hydrostatic Power
steering system, which has a hy-
draulic cylinder and tandem type hy-
draulic pump.
3. DESCRIPTION
