MAINTENANCE AND SERVICE
5-5
5
LUBRICATION CHART
No.
Filling point Fillings Quantity Liter (gal.)
1 RADIATOR
Fresh clean water(L.L.C) with an antifreeze, mixed in ratio of
minimum 50%
3.6ℓ(0.96US gal)
2 ENGINE 2.7 ℓ (0.71 US gal)
3 TRANSMISSION
(API GL-4 Grade)
Tractor transmission and hydraulic oil
Below -4ºF(-20ºC) ISO VG32
Above -4ºF(-20ºC) between ISO VG46
17ℓ (4.5 US gal)
4 FRONT AXLE (API GL-4 Grades)Gear oil #80 or #90 3.2ℓ (0.85 US gal)
5
FRONT AXLE PIVOT
PIN
Grease As required
6 FUEL TANK Diesel fuel 22ℓ(5.81 US gal)
Engine Oil Viscosity
Select the appropriate engine oil viscosity based on the
ambient temperature and use the SAE service grade
viscosity chart
