DESCRIPTION
■ General construction
The transmission case, engine and front axle support are bolted together to form a rigid unit.
■ Front Axle & Wheels
The 4WD front axle is a center-pivot, reverse Eliot type.
The front wheel drive mechanism is incorporated as a part of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in the front axle where the power
is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel.
The 4WD mechanism with level gears provides wider steering and greater durability.
■ Engine
The tractors are fitted with fuel efficient engines with 3 cylinders.
■ Transmission with HST (Hydrostatic Transmission)
The tractor is fitted HST with two range and can be selected speed range by HIGH - LOW selector lever.
The tractor has two pedals for forward/reverse control.
Tractor with Independent Power Take Off is fitted with electro-hydraulic clutch assy.
The Rear PTO and Mid PTO can be operated both or separately by a lever.
■ Brakes
TYM tractors are provided with independent disc brakes.
A parking brake lever is fitted for parking.
GENERAL INFORMATION
2
2-5
