DESCRIPTION OF OPERATING SYSTEM
OPERATING 3-POINT LINKAGE
4. THREE-POINT LINKAGE AND DRAWBAR
Brake Lamp
Remote
Control Valve
(OPTION)
Lift Rod
Check Chain
Lower Link
Retention
Rubber
Brake Lamp
Top Link
Remote
Control Valve
(OPTION)
PTO Shaft
Drawbar
3-18
