DESCRIPTION OF OPERATING SYSTEM
MOUNTING IMPLEMENT
If the PTO is used, remove the safety cover off the PTO shaft.
Adjust the yoke rod on the lower links to suit the implement in use.
Attach the left lower link, then attach the right lower link using the adjusting handle on the leveling box if required.
Attach the top link.
Attach the PTO shaft to the tractor if used, making sure that it is locked in place.
Adjust the check chains to suit the implement and tighten the locknuts.
To remove an implement reverses the procedure.
CAUTION
Do not attach a PTO shaft with the engine running and ensure all safety shields are in place.
PTO ShieldCover
3
3-23
