■ Bleeding the Fuel System
The fuel system is to be bled whenever the tractor has run out of fuel or when filters, pipes or
other components have been replaced.
1. Fill the tank with fuel.
2. Open Fuel filter cock.
3. Turn the key “ON” position for a while.
CHECKING HOSES AND CLAMPS
The fuel lines, radiator hoses, hydraulic and rubber hoses are consumables, which deteriorate
by age and use. Check them regularly and replace if faulty.
■ Checking the Fuel Hoses
1. Park tractor on level surface.
2. Shutoff engine. Allow engine to cool enough.
3. Open the hood.
4. Check the fuel hoses for damage and leakage
5. Replace if required.
6. Tighten clamps.
10 to 12 mm under 10Kgf[98N]
FAN BELT
Check the fan belt tension regularly and adjust if required.
The correct tension is if the center of the belt is pushed.
With a finger it moves in approx. 10 to 12 mm
(0.4 to 0.5 in) under 10Kgf [98N] as shown in the picture.
To adjust the fan belt loosen the top bolt on the alternator, Move the alternator to the desired
position and tighten the bolt.
Also ensure that the bolts at the bottom of the alternator are tight.
MAINTENANCE AND SERVICE
4. Start the engine and allow it to run for a while.
5. Stop the engine.
6. The bleeding of the system is now finished.
5-10
