FRONT AXLE OIL
Use SAE 80 or SAE 90 gear oil for the front axle oil. Do not mix different grades.
■ Checking Front Axle Oil
1. Park tractor on level surface.
2. Lower the implements and shutoff engine.
3. Remove the oil cap.
4. Wipe the dipstick on oil cap. Dip and screw the oil cap into the front axle.
5. Unscrew oil cap and pull out.
6. Check the level with the dipstick. If the level is low add oil through the filler hole.
■ Changing Front Axle Oil
1. Park tractor on level surface.
2. Lower the implements and shutoff engine.
3. Remove the front axle oil cap.
4. Remove the drain plug at the bottom of the front axle case and the drain plugs at the
front of the both spindles.
5. Drain the oil completely into container.
6. Install the drain plugs correctly.
7. Fill with new oil to the correct level in the filler hole.
8. Reinstall the oil cap.
CAUTION
Always ensure that you use the correct oil for topping up or oil changes.
MAINTENANCE AND SERVICE
5-14
