ADJUSTING THE THROTTLE LEVER
If this lever is either loose or difficult to move please consult your dealer for rectification of the problem.
ADJUSTING TOE-IN
If the toe-in adjustment is incorrect it can cause severe shaking of both the steering wheel and the entire tractor.
The correct toe-in is 0.08 ~ 0.24 inch. We recommend that the adjustment is made by the dealer.
TIRE PRESSURE
The air pressure used in the tires has a direct bearing on the life of the tire and its
performance in the field.
Ensure that the tire pressures are correct and in accordance with the table.
To make a visual judgment see the drawing on the right.
IMPORTANT
It is strongly recommended that tire pressures are checked with a proper gauge only & visual inspections are
relied upon.
DANGER
Excess tire pressure can cause accidents!
MAINTENANCE AND SERVICE
5-19
5
