GENERAL INFORMATION
A
8
• REAR AXLE & WHEELS
This is mounted on ball bearings and is
enclosed in removable housing which
are bolted to the transmission case.
The rim & disc fitted with rear tires are
bolted to the outer flange of rear axle.
• HYDRAULIC SYSTEM & LINKAGES
TYM tractors are fitted with live
independent, very touch of hydraulic
system.
Three point linkages can be used for
category 1 type of implements.
• STEERING
It consists of hydrostatic power steering
system, which has a hydraulic cylinder
and single type hydraulic pump.
• ENGINE
The tractors are fitted with vertical,
water-cooled 4-cycle engine.
• TRANSMISSION WITH HST
The Tractor is fitted HST with 2 range
and can be selected speed range by sub
shift lever.
The tractor has two pedals for forward/
reverse control .
Tractor with Independent Power Take
Off is fitted with electro-hydraulic clutch
Assy.
• BRAKES
TYM tractors are provided with
independent disc brakes operated by
two brake rods’ movement.
Use parking brake lever in case of
parking the tractor.
▶ DESCRIPTION
• GENERAL CONSTRUCTION
The transmission case, engine and front
axle support are bolted together to form
a rigid unit.
• FRONT AXLE & WHEEL
The 4WD front axle is a center-pivot,
reverse eliot type.
The front wheel drive mechanism is
incorporated as a part of the axle.
The front wheel drive power is taken off
the rear transmission and transmitted
to the differential in the front axle where
the power is divided into right and left
and to the respective final cases.
In the final cases, the transmitted
revolution is reduced by the level gears
to drive the front wheel.
The 4WD mechanism with level gears
provides wider steering and greater
durability.
