C
TRACTOR INSTRUMENTS
C
5
2. MONITOR PANEL & GAUGES
▶ FIGURE OF MONITOR PANEL
LEFT TURN
SIGNAL LAMP
ONE SIDE BRAKE
WARNING LAMP
LIGHT LAMP (HIGH)
FUEL WARNING
LAMP
TACHO METER
CHARGE WARNING
LAMP
RIGHT TURN
SIGNAL LAMP
LIGHT LAMP (LOW)
ENGINE OIL
PRESSURE
WARNING LAMP
PARKING BRAKE
LAMP
COOLANT
TEMPERATURE
GAUGE
FUEL GAUGE
HOUR METER
CRUISE CONTROL
LAMP
PTO LAMP
GLOW LAMP
