C
TRACTOR INSTRUMENTS
C
▶ LIGHT LAMPS
These lamps come on when light switch
turned on.
▶ TURN SIGNAL LAMPS
This lamp is used to indicate the
intended turning direction of the driver.
When pulling down the turn signal
switch, the left turn signal lamp blinks.
When pushing up the turn signal switch,
the right turn signal lamp blinks.
These lamps are operated when
pressing the hazard warning lamp
switch as well.
▶ COOLANT TEMPERATURE
GAUGE
The gauge shows the coolant
temperature while the key switch is in
ON position.
‘C’ means low to normal temperature
and ‘H’ means high temperature.
If the pointer is in the red H segment,
the engine is overheating.
Refer this book to rectify the problem.
7
LEFT RIGHT
HIGH LOW
