PTO GEAR SELECTION LEVER
Your tractor is equipped with 1 Speed PTO to suit range of applications and conditions.
Always use the clutch when engaging or disengaging the PTO or changing PTO
speed. Let the PTO driven implement come to a complete stop before changing.
important
Do not operate any implement at a high speed than is specified for it.
When making adjustments to the implement stop the engine to avoid serious injury.
When leaving the tractor stop the engine, and remove the key. Set the parking brake.
MODEL
POSITION
1st 2nd 3rd
T433/T503/T553 540 (1000)
42
When leaving the tractor stop the engine, and remove the key. Set the parking brake.
OPERATING THE HYDRAULICS.
The hydraulics are powered with an engine driven hydraulic pump and controlled with a position
control lever mounted beside the driver.
POSITION CONTROL
►
►►
► Implements can be raised and lowered with the hydraulic position control lever and can be stopped
at any position by stopping the lever.
To ensure a consistent working depth the adjustable stop can be set to ensure that the implement
returns to the same depth every time.
To raise the implement: Pull the lever back
To lower the implement: Push the lever forward.
