FILLING DIAGRAM & CAPACITY TABLE
No. Filling point Fillings Quantity Liter (gal.)
MODEL T431/T451
1 RADIATOR Fresh clean Water(L.L.C) 9ℓ(2.38 US gal)
2 ENGINE API : CD/CE grades
Above:25°C(77°F)…SAE30 or 10W-30
0°C to 25°C(32°F to 77°F)…SAE20 or
10W30
Below 0°C(32°F)…SAE 10W or 10W-30
7.0ℓ (1.85 gal)
3 TRANSMISSION CASE See next page * 34ℓ(9 US gal)
4 FRONT AXLE Gear oil #80 or #90 8.8ℓ(2.32 US gal)
5 FINAL DRIVE CASE(B) Gear oil #80 or #90
6 Clutch pedal shaft Grease As required
7 BALL JOINT Grease As required
8 FUEL TANK Diesel fuel 43.5ℓ(11.49 US gal)
58
