Operating the hydraulics.
The hydraulics are powered with an engine driven hydraulic pump and controlled with a electronic
controller mounted beside the driver.
▶ Position control
im
lements can be raised and lowered with the h
draulic
osition
control knob and can be stopped at any position by stopping the
knob
To ensure a consistent working depth the adjustable stop can be set
to ensure that the implement returns to the same depth every time.
- turn the knob till the beep doesn’t operate.
- The sound like beep is normal.
To raise the implement: turn the knob
.
To lower the implement: turn the knob counterclockwise.
1. With the engine started ,the knob doesn’t operate as long as the external hitch
switch is held in the ON position.
2. Self check knob must be in OFF position.
Important
▶ Loader valve
This valve is installed under right side of Step and connected with joy stick.
43
