6) Lift arm sensor
6-1) Put the self check dial to lift arm sensor.
6-2) Insert the ignition key and turn in ON position.
6-3) Control with Position control knob till the beep sound
doesn’t sound.
6-4) Push the external hitch switch in ON position.
6-5) Raise the Hitch(Implement) to maximum height.
6-6) Beep sound is normal.
6-7) Lift arm sensor is not normal if beep sound does not operate.
7-1) Stop movement in the draft load spring by inserting a pin.
7-2) Put the self check dial to load sensor.
7-3) Put the dial to MIN. position.
7-4) Beep sound is normal.
7-5) Load sensor is not normal if beep sound does not operate
The hitch must always be supported on the
locking latches and NOT by the hydraulic
system. If the locking latches do not lock,
adjust the lift rods. If after adjustment the
locking latches still do not lock see your dealer.
Important
To prevent accidents, make sure the hook is fully retracted and the frame is correctly
latched.
Important
After finishing work, always lower the implement to the ground and switch off
the engine, Set the parking brake to avoid injuries and accidents .
Warning
55
