210OPTRS 8 2008
B. SERVICE
WARNING:
Never work in or around the hopper with auxiliary engine
running. Always shut off engine and remove ignition key
prior to servicing.
Aside from routinely washing, the hopper assembly requires very little service.
1. Hopper Hinge - The hopper must be raised in order to access the four grease
zerks used to lubricate the hinge. ALWAYS INSTALL PIN IN SAFETY STRUT
BEFORE WORKING UNDER OR AROUND HOPPER BODY! Lubricate hinge
every 25 hours or once a week.
2. Hopper Seals - The hopper must be maintained air tight for the sweeper to
perform adequately. Daily inspect the dump door seal, right side transition
seal and separator seal. Replace seals if damaged.
