TYPHOON 4000 - Page 15

| 15
1. Spray Tips detergent, 0°, 15°, 25° and 40°: for various high
pressure cleaning applications.
2. High Pressure Hose connect one end to water pump and the
other end to spray gun.
3. Pressure Control Knob varies pressure of high pressure spray.
4. Water Inlet connection for garden hose.
5. High Pressure Outlet connection for high pressure hose.
6. Pump develops high pressure.
7. Oil Level Indicator level should be at halfway
8. Detergent Siphoning Tube/Filter use to siphon pressure blaster
safe detergent into the low pressure stream.
9. Choke Lever prepares a cold engine for starting.
10. Fuel Valve used to turn fuel supply on and off to engine.
11. Recoil Starter used for starting the engine manually.
12. Throttle Lever sets engine in starting mode for recoil starter.
13. Engine Switch set switch to “On” to start engine. Set switch to
“OFF” to stop a running engine.
14. Air Filterprotectsenginebylteringdustanddebrisoutofintake
air.
15. Fuel Tanklltankwithregularunleadedfuel.Alwaysleaveroom
for fuel expansion.
16. Spray Gun Extension with Quick Connect Nozzles controls
the application of water onto cleaning surface with trigger device.
Includestriggerlock.Allowsyoutoswitchbetweenvedifferent
spray tips.
GAS WASHER COMPONENTS
14
16
