TYPHOON 4000 - Frame Assembly; Step-by-Step Frame Assembly

| 35
1. Slide axle spacer (#11) onto axle (#10).
2. Insert axle (# 10) onto 15” Tire (#9) and slide onto the axle
Bracket on the frame.
3. Push Rue Ring Cotter Pin (#5)
into back of axle.
4. Attach Hose Bracket (#6) to
bottom right side of the frame
using 1 each Hex Bolt (#2) SAE Flat Washer (#4) and Flange Nut
(#3).
5. Attach both bottom Wand
Brackets to frame using 2 each Hex Bolt (#2) SAE Flat Washer
(#4) and Flange Nut (#3).
6. Attach both Top Wand Brackets to frame using 2 each Hex Bolt
(#1) SAE Flat Washer (#4) and Flange Nut (#3).
7. Attach Red Battery Cable to the + side of the Battery using 1 each
of Hex Bolt (#12) Flange Nut (#3). Slide the Red Battery Cover
over Battery Post.
FRAME ASSEMBLY
