TYPHOON 4000 - Frame Assembly; Frame Assembly Parts List

| 37
Item No. Part Description Quantity
1 FRAME RIGHT SIDE 1
2 FRAME LEFT SIDE 1
3 FRONT HOOD 1
4 HANDLE ASSEMBLY 1
5 HANDLE BRACKET 2
6 CASTER BRACKET 2
7 FOOT BAR 1
8 BATTERY BOX 1
9 BATTERY BRACKET 1
10 AXLE 2
11 WHEEL SPACER 2
12 SPRINGS WITH CROSS BAR FRONT 1
13 SPRINGS WITH CROSS BAR BACK 1
14 BASE PLATE 1
15 WAND BRAKE BOTTOM RIGHT SIDE 1
16 WAND BRAKE BOTTOM LEFT SIDE 1
17 HOSE BRACKET 1
18 WAND BRAKE TOP LEFT SIDE 1
19 WAND BRAKE TOP RIGHT SIDE 1
20 CASTER ASSEMBLY 2
21 15" TIRE 2
22 SOAP TANK 1
23 ROUND BALE PINS 2
24 RUE RING COTTER PIN 2
25 1/4" - 20 X 2" HEX BOLT 12
26 1/4" - 20 X 1-3/4" HEX BOLT 11
27 1/4" - 20 FLANGE NUT 23
28 1/4" - 20 NYLON LOCK NUT 2
29 1/4" SAE FLAT WASHER 25
30 1/4" - 20 X 3/4" HEX BOLT 2
31 5/16 - 18 X 2" FLAT HEAD SOCKET CAP SCREW 2
32 GROMMET 5
33 RUBBER BUMPER 2
FRAME ASSEMBLY
