SARA-G3 series - System Integration Manual
UBX-13000995 - R06 Objective Specification Design-in
Page 128 of 218
Reference
Description
Part Number - Manufacturer
C1 – C4, C6 –
C9
33 pF Capacitor Ceramic C0G 0402 5% 25 V
GRM1555C1H330JZ01 - Murata
C5, C10 – C12
100 nF Capacitor Ceramic X7R 0402 10% 16 V
GRM155R71C104KA01 - Murata
D1 – D12
Very Low Capacitance ESD Protection
PESD0402-140 - Tyco Electronics
R1, R3
1 kΩ Resistor 0402 5% 0.1 W
RC0402JR-071KL - Yageo Phycomp
R2, R4
470 kΩ Resistor 0402 5% 0.1 W
RC0402JR-07470KL- Yageo Phycomp
R5
47 kΩ Resistor 0402 5% 0.1 W
RC0402JR-0747KL- Yageo Phycomp
J1, J2
SIM Card Holder, 6 + 2 p., with card presence
switch
CCM03-3013LFT R102 - C&K Components
U1
4PDT Analog Switch,
with Low On-Capacitance and Low On-Resistance
FSA2567 - Fairchild Semiconductor
U2
Single 2-Input Digital Multiplexer
74LVC1G157 - NXP Semiconductors
Table 26: Example of components for the connection to two removable SIM cards, with SIM detection implemented
