U-Line 3000 SERIES Installation Guide

2 u-line.com
Grille and Hardware Removal:
1. Loosen (2) 7/64" Allen wrench screws from the grille.
Figure 1 Grille Screw Locations
2. Slide grille forward, pushing tabs in, to remove grille.
Figure 2 Grille Removal
CAUTION
!
To avoid damage to the cord catcher, use care when
removing.
3. Pull down on the cord catcher to remove both the catcher and
its barbed push rivet.
Figure 3 Pulling Down on the Cord Catcher
3 Remove the Door and Frame
A
B
Cord Catcher
Barbed Push
Rivet
