Service and Parts Manual
58
MODEL SP18 (1 of 2)
For Item #8, see Model 402 Ice Maker (page 39) for separate breakdown.
Item Description Part No.
2 Handle 11777
3 Door Gasket 31493-1*
4 Pivot Hinge, Top 11698-SS
5 Pivot Hinge, Bottom 11696-SS
6 Grille 118870
7 Condenser Ass'y 2258-S
8 Ice Maker Ass'y 402
9 Ice Bucket 31429
Item Description Part No.
10 Inner Liner Ass’y/Evaporator 2182-S18
11 Complete Door Ass'y WHT95M-DR
12 Pivot Screw, Top 41747-SSS
13 Pivot Screw, Bottom 41747-SSS
14 On-Off Switch 2053
15 Travel Pin Ass'y TP91-GRY-1
16 Travel Pin (Pin Only) 31476-SS
17 Frame 11810-WHT
6
14
7
17
5
8
9
10
15
16
4
12
13
2
3
11
MODELSP18a
*Please indicate color.
