U-Line 95 Icemaker - Page 61

61
MODEL 75WC
Item Description Part No.
1 Dr Switch Brkt 11712
2 Grille 11664*
3 Wine Shelf 2300
4 Condenser 1951-S
5 Switch 1916
6 Control 2744-S
7 Control Knob-Silver 41715
Alternate Control Knob-Black 41492
8 Lamp Bulb 31317
9 Shelf Clip 31648
10 Drain Cup 11508
11 Drain Pan 31550-1-F
12 Drain Trough 31391-1
13 Hinge, Top RH/Bottom LH 242*
Hinge, Top, 4 Hole 242-1*
14 Hinge, Bottom RH/Top LH 245*
Hinge, Bottom, 4 Hole 245-1*
15 Door Gasket 31493-4*
Item Description Part No.
16 Door Handle 41984-3*
17 Compressor 5400-S
18 Glass Half Shelf (1) 31435
19 Door Ass’y 75WC-DOOR*
20 Light On-Off Switch 2053
21 Lamp Holder 31316-1
22 Overload 5411
23 Back Panel 11769
24 Light Cover 31314
25 Dryer 2694
26 Fan Motor 5263
27 Fan Blade 5188
28 Power Cord 2240
29 Evaporator & Heat Exchanger 2186-S
30 Leveler Feet (4) 41319
31 Lock Ass’y 41734-S
32 Relay 5412
19
30
29
25
11
26
27
28
17
23
14
31
16
13
15
10
12
2
5
6
7
20
4
18
3
9
24
8
21
22
32
1
MODEL75WC
*Please indicate color.
MODEL75WC
