Reversing Black or White Doors
• The hinge hardware will be removed and reinstalled on the
opposite side of the cabinet.
• The top hinge hardware will be reinstalled on the bottom of the
opposite side of the cabinet.
• The bottom hinge hardware will be reinstalled on the top of the
opposite side of the cabinet.
Remove Door
1. Hold door to keep it from falling.
2. Remove hinge screw pin (1) from top hinge using a Phillips
screwdriver.
3. Remove door by tilting forward and lifting door off bottom hinge
closer inserts.
4. Reinstall hinge screw pin (1) into top hinge using a Phillips
screwdriver.
Remove hole plugs.
Remove plastic screw plugs (three each, top and bottom) (3)
from new hinge location. Save for reinstallation later.
Remove existing top hinge.
Remove existing top hinge (three screws) (2).
Reinstall hinge to bottom opposite.
1. Install the hinge just removed from the top to the BOTTOM
opposite side of the cabinet (three screws) (2).
2. Remove the two door closer inserts (4) from the existing
bottom hinge.
3. Install door closer inserts as shown on the new bottom hinge
(4).
3
1
2
4
4
