Ubee UBC1301-AA00 Advanced Wireless Voice Gateway Subscriber User Guide • March 2017 34
6Understanding the Gateway Menu
The Gateway option provides the majority of configuration for the device including WAN
and LAN setup, wireless settings, parental control, advanced gateway options such as
MAC filtering and port forwarding, device diagnostics, and device management options.
See the following topics:
Using the WAN Option on page 34
Using the LAN Option on page 37
Using the WLAN Option on page 41
Using the Advanced Settings Options on page 54
Using the Parental Control Option on page 71
Using the Management Option on page 74
Using the Diagnostics Option on page 78
To access the gateway menu:
1. Access the Web user interface. Refer to Accessing the Web User Interface Locally on
page 18.
2. Click Gateway from the top main menu.
6.1 Using the WAN Option
Use the WAN option to view information regarding the WAN interface of the UBC1301-
AA00.
To view WAN interface information:
1. Click Gateway from the main menu.
2. Click WAN on the left side menu.
3. The following sub-menus are available for selection:
Using the Setup Option on page 35
Using the Operation Mode Option on page 36
To Next Page
