Ubee UBC1301-AA00 User Manual

Ubee Interactive Using the Advanced Settings Options
Ubee UBC1301-AA00 Advanced Wireless Voice Gateway Subscriber User Guide • March 2017 54
The following diagram displays the channels available in the Americas. Each available
channel is 22MHz wide. Since channels overlap, it is best to choose channels that have
the least overlap (typically 1, 6, and 11 in the Americas, and 1, 5, 9, and 13 in Europe).
Overlapping channels can cause wireless network performance issues.
Source: Wikipedia.org, and IEEE article IEEE 802.11n-2009
5GHz Channels
The following table shows the 5GHz channel list and the corresponding frequencies.
6.4 Using the Advanced Settings Options
Advanced options provide many settings to configure your UBC1301-AA00.
To view Advanced Settings options:
1. Click Gateway from the main menu.
2. Click Advanced Settings on the left side menu.
3. The following sub-menus are available for selection:
 Using the Options option on page 55
 Using the Firewall option on page 56
 Using the IP Filter Option on page 57
 Using the MAC PassThrough Option on page 58
Channel GHz Channel GHz
36 5.180 108 5.540
40 5.200 112 5.560
44 5.220. 116 5.580
48 5.240 136 5.680
52 5.260 140 5.700
56 5.280 149 5.745
60 5.300 153 5.765
64 5.320 157 5.785
100 5.500 161 5.805
104 5.520 165 5.825

Ubee UBC1301-AA00 Specifications

General

Brand	Ubee
Model	UBC1301-AA00
Category	Gateway
Language	English
