Ubee Interactive Using the Advanced Settings Options
Ubee UBC1301-AA00 Advanced Wireless Voice Gateway Subscriber User Guide • March 2017 63
5. Click Apply. The forwarding rule is created and displayed in the table as shown
below. Additional field descriptions follow.
Label Description
Type Allows you to select either IPv4 or IPv6.
Local IP
Defines the IP address of the local LAN device to which the forwarding rule applies. For
example, an Xbox or PC.
Local Start Port Defines the starting port number listened to by the server host located in your LAN.
Local End Point Defines the ending port number listened to by the server host located in your LAN.
External Start Port Defines the port number to start the range of ports to publish to the Internet.
External End Port
Defines the port number to end the range of ports published to Internet.
Note: Be very careful with ranges. Ports within a range are not usable by other
applications that may require them. It is common and safer to enter the same port
number as the start and end of the range.
Protocol Selects the protocol type. Options are TCP, UDP or TCP/UDP.
Description Specifies the forwarding rule name.
Enabled Disables (Off) or enables (On) the forwarding rule.
Apply Saves the forwarding rule.
Cancel Cancels the rule.
