Ubiquiti EdgeRouter 12 User Manual

Configuring PoE Settings
The PoE setting for port 9 is set to Off by default.
WARNING: Before activating PoE, ensure that the
connected device supports passive PoE and the
supplied voltage.
1. In the Dashboard tab, click Actions > PoE of the Ethernet
port you want to configure.
12
6
7
6
8
7
9
Disconnected
Disconnected
2. The Interface Configuration window will appear. Select the
appropriate PoE setting, and click Save.
Port 9
Port 9
3. The Ethernet port’s PoE LED will confirm the PoE setting.
For detailed instructions on configuring other features, please
refer to the EdgeOS User Guide. The User Guide is available at
www.ubnt.com/download/edgemax

Ubiquiti EdgeRouter 12 Specifications

General

RAM	1 GB DDR3
Flash Storage	4 GB eMMC
Total Ports	12
Gigabit RJ45 Ports	10
SFP Ports	2
Max Power Consumption	20W
Operating System	EdgeOS
Layer 3 Forwarding Performance	3.4 million pps
Total Non-Blocking Throughput	10 Gbps
Certifications	CE, FCC, IC
Power Supply	24V, 1A
Supported Voltage Range	100-240V
Operating Humidity	10 to 90% Noncondensing
Operating Temperature	-10 to 45° C
