27
JP1
20 IO15 FPGA Counter Output to RCM3400 (Bit 3)
21 IO16 FPGA Counter Output to RCM3400 (Bit 16)
22 IO17 FPGA Counter Output to RCM3400 (Bit 4)
23 IO18 Channel B Signal In
24 IO19 FPGA Counter Output to RCM3400 (Bit 5)
25 IO20 FPGA Counter Output to RCM3400 (Bit 17)
26 IO21 Coincidence Window or Delay (Bit 1)
27 IO22 FPGA Counter Output to RCM3400 (Bit 18)
28 IO23 Coincidence Window or Delay (Bit 2)
29 +3.3V Not Connected
30 GND2 Ground
31 IO24 FPGA Counter Output to RCM3400 (Bit 20)
32 IO25 FPGA Counter Output to RCM3400 (Bit 8)
33 IO26 Channel GATE Signal In
34 IO27 FPGA Counter Output to RCM3400 (Bit 9)
35 IO28 FPGA Counter Output to RCM3400 (Bit 13)
36 IO29 FPGA Counter Output to RCM3400 (Bit 10)
37 IO30 FPGA Counter Output to RCM3400 (Bit 6)
38 IO31 FPGA Counter Output to RCM3400 (Bit 11)
39 IO32 FPGA Counter Output to RCM3400 (Bit 7)
40 IO33 FPGA Counter Output to RCM3400 (Bit 12)
JP2
1 IN0 Not Connected
2 IO00 Not Connected
3 IN1 Not Connected
4 IO01 Not Connected
5 IO02 Not Connected
6 IO03 Not Connected
7 IO04 Not Connected
8 IO05 Not Connected
9 IO06 Not Connected
10 IO07 Not Connected
11 +5V Not Connected
12 GND Ground
13 IO08 Clear FPGA Counter Bit
14 IO09 Not Connected
15 IO10 Enable GATE Signal Flag for FPGA
16 IO11 Not Connected
17 IO12 Channel Select for FPGA Counter (Bit 0)
18 IO13 Not Connected
19 IO14 Channel Select for FPGA Counter (Bit 1)
20 IO15 Not Connected
21 IO16 FPGA Counter Output to RCM3400 (Bit 19)
22 IO17 Not Connected
23 IO18 FPGA Counter Output to RCM3400 (Overflow Bit)
24 IO19 Not Connected
25 IO20 FPGA Counter Output to RCM3400 (Bit 21)
26 IO21 Not Connected
27 IO22 Not Connected
28 IO23 Not Connected
